Especificaciones:

• Tipo: Piezas de ventilador
• State indication: Green LED indication
• Output voltage range: 1-60VDC
• Output current: 2A
• Operative Standard: IEC60664,EN50178,IEC62103
• Operation frequency: less than 100Hz
• Número de modelo: MRD-060D2
• Name: Solid State Relay
• Max voltage: less than 0.2V
• Input voltage range: 4-32VDC
• Input/output Isolation Voltage: 2.5kV(50Hz,1min)
• Input current: less than 15mA
• Dimension: 81x6.2x78mm
• Contact material: Power MOSFET
• Circuit protection: Diode reverse protection
• Applicable wire(Ridigity/Flexibity): 0.2-2.5mm2
• Applicable wire(AWG): 24-14
• Ambient Temperature: -20 to +60 degree celsius
