Especificaciones:

• Tipo: Piezas de ventilador
• State indication: Green LED indication
• Output voltage range: 24-264VAC
• Output current: 5A
• Operative Standard: IEC60664,EN50178,IEC62103
• Operation frequency: 3Hz
• Número de modelo: MRA-23D5
• Name: Solid State Relay
• Max voltage: less than1.2V
• Input voltage range: 3-32VDC
• Input/output Isolation Voltage: 2.5kV(50Hz,1min)
• Input current: less than 15mA
• Dimension: 81x6.2x79mm
• Contact material: TRICA
• Circuit protection: polarity protection circuit
• Applicable wire(Ridigity/Flexibity): 0.2-2.5mm2
• Applicable wire(AWG): 24-14
• Ambient Temperature: -20 to +60 degree celsius
